Product Introduction

The cuttings drying function can effectively recover the liquid component in the cuttings and make the solid phase very dry. It is suitable for water-based mud, oil-based mud and synthetic mud to recover mud from drilling cuttings, thereby reducing drilling costs and environmental pollution.

Its processing capacity is 40 to 60 tons/hour, and the treated cuttings liquid/oil content is less than 5% (w/w), which meets international emission standards and environmental protection requirements. It can be applied to the treatment of drilling cuttings in both onshore and offshore drilling.

Performance characteristics

1. The rotating parts adopt vertical design, smooth operation and small vibration.

2. The main parts are made of corrosion-resistant steel, manganese steel or other materials.

3. The cone Angle of the drum can be selected according to the process conditions.

4. Special strip filter metal mesh, better wear resistance, longer service life.

5. Feed, separation, dehydration, discharge continuous completion, large capacity.

6. Independent lubrication system, simple and reliable operation.

7. 3K planetary gear box, impact structure, high torque.

Technical parameter
